Manoeuvrable collection. Powerful compaction. Versatile disposal.
MUT press plate superstructures
MUT's press plate vehicles offer robust and versatile solutions for the efficient collection of residual waste, bulky waste, commercial waste, paper, cardboard and plastics. Our press plate systems demonstrate their strengths wherever maximum compaction, high collection capacity and flexible operating conditions are required.
Whether electrically or hydraulically operated, our press plate superstructures are compatible with chassis from all well-known manufacturers and, thanks to variable sizes and configurations, adapt perfectly to urban, industrial and municipal requirements.
PRESS MUT
Mega MUT
The PRESS MUT impresses with its outstanding reliability and exceptional versatility. It collects a wide variety of waste fractions – from household and residual waste to cardboard, paper and plastics. For particularly wet or organic waste, a biodense version is also available, which effectively prevents leaks and odours.
In order to meet a wide range of application requirements, the PRESS MUT is available in several design variants. In addition to the proven frame construction (optionally with or without external cladding), we also offer modern ‘curved body’ containers. This design ensures a particularly robust, smooth and easy-to-clean structure.
In combination with our newly developed, shortened rear section, the PRESS MUT in the ‘curved body’ version is one of the most compact press plate vehicles on the market. For you, this means greater manoeuvrability in urban areas, more payload and more efficient routes.
PRESS MUT
| Volume in m³ | Wheelbase in mm | Width in mm | Length in mm | Height in mm | Axles | Weight in kg | GVW in t | Payload in kg** |
|---|---|---|---|---|---|---|---|---|
| 16 | 3,600-3,900 | 2,500 | 5,605 | 2,500 | 2 | 5,754 | 18 | 6,446 |
| 18 | 3,900-4,200 | 2,500 | 6,081 | 2,500 | 2 | 6,094 | 18 | 6,106 |
| 20 | 3,100-3,600 | 2,500 | 6,554 | 2,500 | 3 | 6,300 | 26 | 11,700 |
| 22 | 3,700-4,000 | 2,500 | 6,956 | 2,500 | 3 | 6,440 | 26 | 11,560 |
| 24 | 4,400-4,600 | 2,500 | 7,376 | 2,500 | 4 | 6,510 | 32 | 16,090 |
| 26.5 | 4,500-4,900 | 2,500 | 7,646 | 2,630 | 4 | 6,520 | 32 | 16,080 |
The MEGA MUT is designed to handle even the most stubborn materials. This makes it the ideal choice for collecting bulky waste, commercial waste, waste wood or garden waste. Its reinforced container and loading structure enable even higher pressing force than the PRESS MUT.
The MEGA MUT is available with a loading volume of 20 m³ to 24 m³, with or without a lifter. This versatility makes it an all-rounder in your fleet.
When combined with the AU-P Mega Lifter, the MEGA MUT becomes a true all-rounder. The system combines DIN gripper arms, a comb lifting system and a pocket holder, offering maximum flexibility. This allows your teams to empty all of the following containers during a single tour:
MEGA MUT
| Volume in m³ | Wheelbase in mm | Width in mm | Length in mm | Height in mm | Axles | Weight in kg | GVW in t | Payload in kg** |
|---|---|---|---|---|---|---|---|---|
| 20 | 3.100-3,600 | 2,500 | 6,654 | 2,505 | 3 | 6,980 | 26 | 11,020 |
| 22 | 3,700-4,000 | 2,500 | 7,059 | 2,505 | 3 | 7,230 | 26 | 10,770 |
| 24 | 4,400-4,600 | 2,500 | 7,477 | 2,505 | 3/4 | 7,490 | 26/32 | 11,440 |
| 26.5 | 4,500-4,900 | 2,500 | 7,747 | 2,630 | 4 | 7,750 | 32 | 12,240 |
Superstructure and lifting system from a single source
MUT EcoLift
The fully electric MUT EcoLift lifts, tips and empties all standard 2-wheel and 4-wheel containers in accordance with EN 840 – quietly, cleanly and with exceptional energy efficiency. Depending on the application requirements, it is available as a manual, semi-automatic or fully automatic version, making it perfectly adaptable to different route concepts.
The precise electrical control ensures safe, quiet operation and enables ergonomic handling for the team on duty.
As an integrated solution from Steyr Automotive, customers benefit from a decisive advantage: body and lifting system from a single source – optimally coordinated, easy to maintain and reliable in daily use. This makes the EcoLift the ideal choice for modern, efficient and sustainable waste collection.
